t100W/t100Q – Marine Satellite T
elevision System
126
Antenna Backup & Restore
No.
Item
Description
1
Antenna Backup & Restore
Enter Backup & Restore page. (Setup mode is
requir
ed)
2
T
ar
get
Backup antenna information to ACU/PC or
restor
e antenna by using the saved information
from ACU/PC.
3
Backup
Backup antenna information.
4
Restore
Restore antenna information.
1
3
4
2
125
127
