Intellian t100W User Manual

t100W/t100Q – Marine Satellite Television System
50
INTELLIAN TECHNOLOGIES INC.
INTELLIAN t100W
1. The data communication is being established between the antenna and the ACU.
INITIALIZE - ANTENNA INFO
INTELLIAN t100W
2. The ACU receives antenna information.
INITIALIZE - EL POSITION
INTELLIAN t100W
3. The elevation angle and cross level angle are initialized.
INITIALIZE - AZIMUTH POSITION
INTELLIAN t100W
4. The azimuth angle is initialized.
INITIALIZE - FIND NOISE LEVEL
INTELLIAN t100W
5. The antenna measures the noise levels of the default satellites.
INITIALIZE - SAT POSITION
INTELLIAN t100W
6. The antenna returns to the target satellite position.
7. The antenna is searching for the target satellite.
8. The antenna has locked onto the target satellite and is now tracking.
Startup
With the system installed and power applied, the ACU screen will show the following
sequence.
Normal Mode
SEARCH 19.2E ASTRA_1 AGC :301• VL
AZ :160.9(
3
40.9) EL:29.0 SK:-21.1 Fn
TRACKING 19.2E ASTRA_1 AGC :301• VL
AZ :160.9(
3
40.9) EL:29.0 SK:-21.1 Fn
