57
OPERATING THE ACU
Installation Settings
SETUP MODE ?
4
YES NO
1. Press the LEFT arrow key to move cursor to YES and press the OK key to enter setup
mode.
+ANTENNA +SATELLITE
+SYSTEM
4
+INSTALLATION
2. Press the arrow keys to move cursor to INSTALLATION and press the OK key to enter
INSTALLATION menu.
3. Press the arrow keys to select parameter you wish to edit and press the OK key
to edit the selected parameter. To save, abort, and return to the main display, press the
BACK key.
4. Set the CONTINENT.
Press the UP and DOWN arrow keys to select the continent that you are in.
Press the OK key to set the CONTINENT.
5. Set the REGION.
Press the UP and DOWN arrow keys to select the region that you are in.
Press the OK key to set the REGION.
6. Set the current LATITUDE .
Press the LEFT and RIGHT arrow keys until the desired character is underscored (selected).
Press the UP and DOWN arrow keys to increase or decrease the value, or press the NUMBER
keys to set the desired value directly.
Press the OK key to set the LATITUDE.
Installation
4
SELECT CONTINENT SELECT REGION
EUROPE NETHERLANDS
SELECT CONTINE N T SELECT REGION
EUROPE NETHERLANDS
SELECT CONTINE N T SELECT REGION
EUROPE
NETHERLANDS
LATITUDE LONGITUDE
52.22N 4.53E
To Next Page
