t100W/t100Q – Marine Satellite Television System
16
The functions of the ACU are as follows :
• System startup
• Change of target satellite
• Monitoring current status
• Setting antenna manual search
• Setting antenna set skew
• Setting antenna search parameter
• Setting antenna set parameters
• Executing antenna diagnosis
• Setting the satellite pair
• Edit satellite information
• Setting the region
• Finding transponders
• Setting the GPS and Gyrocompass
• System backup & restore
• Copy log and rmware upgrade through USB
• Supports Wi-Fi ACU operation
• Built-in web-based remote control management
• Front panel Management Ethernet port
• Installation settings
Installation Kit
Contains the items required for mounting the antenna unit and ACU to your
vessel.
Antenna Q’ty Description Size Remark
5
Hex. Bolt M12 x 100L
Antenna-Deck
5
Flat Washer M12
5
Spring Washer M12
10
Hex. Nut M12
To Next Page
