INSTALLING THE ANTENNA
Item Image Q’ty Description Size Remark
1
2
ACU
Bracket
Rack - ACU-19inch Rack
2 Table - ACU-Table
2
1 RG6 Cable 15m
ACU to Receiver
1 RG6 Cable 3m
3 1
AC Power Cord
(CEE7/7)
1.5m ACU Power
4 1 PC Serial Cable 1.8m ACU to PC
ACU Q’ty Description Size Remark
5
Self-Tapping
Screw
ø4 x 16
Table Mount
Bracket
10
Flat Head Screw M4 x 12L
Rack Mount
Bracket ACU
5
Sems Bolt M3 x 12L
Table Mount
Bracket ACU
Other Components
