t100W/t100Q – Marine Satellite Television System
20
System Cables
Before installing the system cables, you need to take the following points into
consideration.
• All cables need to be well clamped and protected from physical damage
and exposure to heat and humidity.
• A cable with an acute bend is should be avoided.
• Wherever a cable passes through an exposed bulkhead or deck head,
a watertight gland or swan neck tube should be used.
RF Cables (Customer Supplied)
Due to signal loss across the length of the RF coax on L-Band, Intellian recommends
the following 75 ohm coax cable types for standard system installations. For cables
that run longer than 100 meters, please consult Intellian Technologies.
Run Length Coaxial Cable Type
Up to 35 meters RG-6 or LMR-300-75
Up to 60 meters RG-11 or LMR-400-75
Up to 100 meters LMR-600-75
Power Requirements
The Intellian t100W/t100Q has been designed to work on a vessel’s power supply
rated at 110-220 V AC.
Type Multi-conductor, Shielded
Number of wires 2 conductors for NMEA 0183,
5 conductors for NMEA 2000
Gyrocompass / GPS Interface Cable (Customer supplied)
