Antenna Settings
Setting Antenna Manual Search
SETUP MODE ?
4
YES NO
1. Press the LEFT arrow key to move cursor to YES and press the OK key to enter SETUP
mode.
4
+ANTENNA +SATELLITE
+SYSTEM +INSTALLATION
2. Press the OK key to enter ANTENNA menu.
4
+MANUAL SEARCH +SET POL ANGLE
+SEARCH PARAM +SET PARAMETERS
3. Press the OK key to enter MANUAL SEARCH menu.
STEP SIZE AZIMUTH ELEVATION AGC
#
0.2 # 288.7 41.0 288 Fn
4. Current IF signal level (AGC) is displayed to assist you in manually peaking EL for best
signal level. Press the NUMBER key to change the step size(Range : 0.1~9.9). Press the
LEFT and RIGHT arrow keys to move azimuth by step size (Range : 0~360). Press the UP
and DOWN arrow keys to move elevation by step size (Range : 0~90). Press the FUNCTION
key to save the bow offset when the antenna locks onto the peak level of the AGC signal.
SAVE CURRENT SAT INFO?
4
YES NO
5. If the current settings are able to lock onto the satellite, press the LEFT key to move cursor
to YES and press the OK key to save the bow offset. It will shorten the satellite acquisition
time next time, or you can press the RIGHT key to move cursor to NO and press the OK key
to abort and return to the previous view.
To Next Page
