Setting Location
1. Press the LEFT arrow key to move cursor to YES and press the OK key to enter setup
mode.
2. Press the DOWN arrow key to move cursor to SYSTEM and press the OK key to enter
SYSTEM menu.
4
+SET LOCATION +MANAGEMENT
+KEY LOCK
3. Press the RIGHT arrow key to move cursor to SET LOCATION and press the OK key to
enter SET LOCATION menu.
GYRO TYPE BAUDRATE
NMEA
4800
4. Set the ship’s GYRO TYPE* and BAUD RATE
A search pattern 1 or 3 will be initiated according to which GYRO TYPE is selected and the
existence of the gyro input. Set the BAUD RATE as 4800,9600,19200 or 38400 according to
your device.
A search pattern 1 will be initiated automatically if the gyro input does not exist, and if the
gyro type selected is different than GROUND TEST.
Note: The bow offset will not be saved automatically if Search 1 pattern is initiated. In this
case, the antenna will need to retarget the desired satellite using Search 1 every time if the
antenna restarts.
Setting of Heading Device
Existence of Heading Data None NMEA / NMEA 2000 Ground Test
With Heading Data Search 1 Search 3 Search 3
Without Heading Data Search 1 Search 1 Search 3
System Settings
SETUP MODE ?
4
YES NO
+ANTENNA +SATELLITE
4
+SYSTEM +INSTALLATION
