61
OPERATING THE ACU
Setting POL. Angle
SETUP MODE ?
4
YES NO
1. Press the LEFT key to move cursor to YES and press the OK key to enter setup mode.
4
+ANTENNA +SATELLITE
+SYSTEM +INSTALLATION
2. Press the OK key to enter ANTENNA menu.
+MANUAL SEARCH
4
+SET POL ANGLE
+GO POSITION +SEARCH PARAMETERS
3. Press the RIGHT arrow key to move cursor to SET POL ANGLE and press OK key to enter
SET POL ANGLE menu.
SELECT LNB POL. ANGLE MENU
CALIBRATION
4. Press the UP and DOWN arrow keys to select the menu and press the OK key to run the
selected operation ‘ CALIBRATION ‘ or ‘ MANUAL ADJUST‘. When you replace the control
board, select CALIBRATION to calibrate LNB skew angle.
5. Press the UP and DOWN arrow keys to increase or decrease the LNB skew angle manually.
Press BACK key to return to main display.
Press the LEFT and RIGHT arrow keys to select the polarization between Linear and Circular.
Press BACK key to return to main display.
LNB POL ANGLE POLARITY SIGNAL :180
20.0 LINEAR
To Next Page
