OPERATING THE ACU
8. Press the RIGHT arrow key to display current satellite, GPS and ship’s heading [ HDG ]
information.
Satellite Information :
Frequency : 11509 MHz
Symbol rate : 22000 kSps
Verication method : DVB_ Decode
LNB local frequency : 9750 MHz
GPS Information :
Longitude : West /East
Latitude : North/South
9. Press the RIGHT arrow key to display ACU and antenna ,LNB and IRD voltage information.
Antenna and ACU Voltage :
Due to the voltage loss across the multi-conductor cables, ensure that the minimum ACU
operation voltage is within 27V, and minimum antenna operation voltage is above 16V.
LNB and IRD Voltage :
13 V + 0KHz (Vertical Low)
18V + 0KHz (Horizontal Low)
13V + DiSEqC 22 KHz tone (Vertical High)
18V + DiSEqC 22 KHz tone (Horizontal High)
10. Press the RIGHT arrow key to display Antenna, ACU and Library version.
Keep pressing the RIGHT arrow key to return to the main display.
DVB_D F:11509 S:22000 X0001 AG
C
:301
4.53E 52.22N HDG:000.0 L:9750 Fn
[PWR] ANT: 23.9V LNB:13V + 0KHz
ACU: 27.0V IRD:13V + 0KHz
T3-101AW23 ANT.Serial 4.00/
4
.00
BP-TA31 ACU Serial 4.00(
2
.00)
NOTE: If you have any problems while performing these steps, contact the Intellian
service team for support.
