69
OPERATING THE ACU
Executing Antenna Diagnosis
SETUP MODE ?
4
YES NO
1. Press the LEFT key to move cursor to YES and press the OK key to enter setup mode.
4
+ANTENNA +SATELLITE
+SYSTEM +INSTALLATION
2. Press the OK key to enter ANTENNA menu.
4
+DIAGNOSTIC
3. Press the arrow keys to move cursor to DIAGNOSTIC and press the OK key to enter
DIAGNOSTIC menu.
DIAGNOSTIC FULL TEST
FULL TEST READY
4. Press the UP and DOWN arrow keys to select a full diagnosis or single diagnosis and press
the OK key to execute the selected diagnosis.
DIAGNOSTIC FULL TEST
FULL TEST
- 5
5. A full diagnosis is completed.
DIAGNOSTIC COMMUNICATION
CODE 101 RESULT : PASSED
6. The diagnosis result is shown.
To Next Page
