Intellinet 561099 User Manual

8‐PortGigabitWeb‐SmartSwitch
22|Page

4.3 PortMirroring
Networkengineersoradministratorsuseportmirroringtoanalyzeanddebugdataordiagnoseerrorsona
network.Ithelpsadministratorskeepacloseeyeonnetworkperformanceandalertsthemwhen
problemsoccur.Itcanbeusedtomirroreitherinboundoroutboundtraffic(orboth)onsingleormultiple
interfaces.Portmirroringisusedonanetworkswitchtosendacopyofnetworkpacketsseenonone
switchport(oranentireVLAN)toanetworkmonitoringconnectiononanotherswitchport. 



Thefollowingtabledescribesthelabelsinthisscreen.

LABEL  DESCRIPTION 
MirrorDirection Rx:Receivedtraffic
Tx:Transmittedtraffic
Both:Transmittedandreceivedtraffic
MirroringPort Definewhichportwilloutputthemirroredtraffic.Thisistheporttowhichyou
connectyourmonitoringstation.
MirroredPortList Definewhichofthe8portsyouwishtomirrorthetrafficfor.Notethatthe
mirroredportcannotbethesameasthemirroringport.
Apply  ClickApplytocreatethenewportmirroringrule.
Delete ClickDeletetoremovetheportmirrorrule.



Note:
Youcanonlycreateoneportmirroringruleatatime.
Youcanonlymirrorthecontentsfromoneporttooneotherport,butnotmirrorthecontentsofmultiple
ports.


