Intellinet 561099 - 802.1 Q VLAN

8‐PortGigabitWeb‐SmartSwitch
27|Page

5.4 802.1QVLAN
Allowsyoutocreatevirtualnetworksusing802.1Q.Whenusing802.1QVLAN,youconfigureportstobea
partofaVLANgroup.WhenaportreceivesdatataggedforaspecificVLANgroup,thedataisdiscarded
unlesstheportisamemberoftheVLANgroup.Thistechniqueisusefulforcommunicatingwithdevices
outsideofyourlocalnetworkaswellasstillreceivingdatafromotherportsnotinyourVLANgroup.It
requiresthatyouknowtheVLANgroupIDsused.

5.4.1 802.1QStaticVLAN
Onthispagetheusercanconfigurethe802.1QStaticVLANfeatureandtherelatedsettings. 


LABEL  DESCRIPTION 
VLANID EntertheIDnumberofVLAN.Validvaluesare1to4094.
VLANName  OptionalnamefortheVLAN. 
Port Displaystheportnumberoftheswitch.
SelectAll Clicktoquicklyselectallportsatonce.
Untagged Configuretheegressruleofthetrafficontheportasuntagged.Theswitchdrops
thetagheaderbeforeforwardingthepacket.
Tagged Configuretheegressruleofthetrafficontheportastagged.Theswitchaddsthe
tagheaderbeforeforwardingthepacket. 
NotMember Port(s)notmember(s)oftheVLANgroup.
Apply  ClickApplytoactivatethesettings.



Note:
ThedefaultVLAN(VID=1)cannotberemovedbutyoucansettountagged/taggedandmodifythe
memberports.

