6.2 BandwidthControl
Policing,orratelimiting,allowsyoutolimitthedataratesforaparticularportontheIntellinet8‐Port
GigabitWeb‐SmartSwitch.Whenthedatarateexceedsuser‐configuredvalues,theIntellinetswitchdrops
packetsimmediately. 

Ratelimitingisconfiguredfortwotypesoftransmissions,whichareingressandegress.Ingresstrafficis
receivedonanygivenport(incoming,inboundordownload),whereasegresstrafficistrafficsentout
(outgoing,outboundorupload)toanothernetworkclient.



Thefollowingtabledescribesthelabelsinthisscreen.

LABEL  DESCRIPTION 
Port Selectthedesiredportforrateconfiguration.HolddownCTRLtoselectmultiple
portsatonce.
Type SelectIngressorEgressfromthedrop‐downbox.
State EnableorDisablebandwidthcontrol fortheselectedport.Setthistoenable,or
thevalueswillnotbesaved.
Rate Selectthemaximumtransmissionratefortheselectedports. 




Note:
Whenegressbandwidthcontrolisenabledforoneormultipleports,itisrecommendedtodisableflow
controloneachporttoensurethattheswitchcontinuestoworksnormally. 
