Intellinet 561099 - 802.1 Q VLAN Port

8‐PortGigabitWeb‐SmartSwitch
28|Page



LABEL  DESCRIPTION 
VLANID DisplaystheIDnumberoftheVLAN.
VLANName DisplaysthenameoftheVLAN.
MemberPorts DisplaysthememberportsoftheVLAN.
TaggedPorts Displaysthetaggedmemberports of theVLAN.
UntaggedPorts DisplaystheuntaggedmemberportsoftheVLAN. 
Delete ClickDeletetoremovetheselectedVLANID.
SelectALL Clicktoquicklyselectallportsatonce.


5.4.2 802.1QVLANPort
ThispageshowsVLANportinformation.TheusercanassignaPVIDnumber,andtheacceptedframetype
foreachport.






