2.5 HardwareInstallation
DesktopInstallation
Placetheswitchonaflatsurface.Ensureadequateventilationspacearoundtheswitchfordissipating
heatandair.Properlyconnectthedevicetoapoweroutletusingtheincludedpowercable,anditwill
automaticallyinitializeandthepowerLEDwilllightup.

InstallingNetworkCables
Tomakeavalidconnectionandobtaintheoptimalperformance,anappropriatenetworkcablethat
correspondstodifferenttransmitting/receivingspeedsisrequired.Tochooseasuitablecable,pleaserefer
tothefollowingtable.

Media Speed Wiring
NetworkMedia
(Cable)
10Mbps
10Base‐T:UTPcategory3,4,5cable(maximum100m)EIA/TIA‐568
100ΩSTP(maximum100m) 
100Mbps
100Base‐TX:UTPcategory5,5ecable(maximum100m)EIA/TIA‐568
100ΩSTP(maximum100m)
1000Mbps
1000Base‐T:UTPcategory5e,6cable(maximum100m)EIA/TIA‐568
100ΩSTP(maximum100m)

2.6 ConnecttoWebAdminInterface
InordertoconfigurethesmartfeaturesoftheIntellinet8‐PortGigabitWeb‐SmartSwitch,youneedtoset
theIPaddressofyourcomputer’snetworkadaptertoavalueof192.168.2.xxxwherexxxmustnotbe
equalto1.RefertoAppendixAfordetails.

ThedefaultIPoftheIntellinet8‐PortGigabitWeb‐SmartSwitchis192.168.2.1.Open“http://192.168.2.1”
inyourwebbrowser.


Theloginscreenappears. 
UserName:‘admin’
Password:‘1234’



