8‐PortGigabitWeb‐SmartSwitch

5|Page



2 Introduction

2.1 GeneralDescription

Thedeviceisahigh‐performanceGigabitEthernetswitch,withall8portscapableof10/100/1000Mbps

auto‐negotiationoperation(NWay)whichmeanstheswitchcouldautomaticallynegotiatewiththe

connectedpartnersonthenetworkspeedandduplexmode.

ThisswitchsupportstheWebGUItocontroleachportstatusandbandwidthcontrolbyportratelimiting.

It’seasytosettheVLAN&QoSfunctions,theVLANincludesMTUVLAN,PortBaseVLAN&802.1QVLAN.

TheQoShas4priorityqueueswhichcansettheStormFilterforBroadcastStorm,MulticastStorm&

UnicastStorm.Loopdetectionandpreventionfunctionsaresupportedfordetecting/resolvingthecable

loopbackconnectionissuemoreeasily.SupportsDHCPSnoopingfunctiontopreventun‐trustedDHCP

serverinstalledforeasilymaintainingnetworkmanagement.

TheswitchcomplieswithIEEE802.3azEnergyEfficientEthernettosavepowerconsumption,andsupports

IGMPSnoopingtoimprovetrafficperformance.Moreover,therichdiagnosticLEDsonthefront‐panel

providetheoperatingstatusofindividualportsandthewholesystem.



2.2 KeyFeatures

 8xRJ‐45portsfor10/100/1000Mbpsconnectivity

 AllRJ45portswithAuto‐MDIX(autouplink)support

 Supports802.3xflowcontrolforfullduplexmodeandcollision‐basedbackpressureforhalfduplex

mode

 ComplieswithIEEE802.3azEnergyEfficientEthernet

 SupportsEEEenableanddisable

 SupportsIEEE802.3xFlowControl

 Supportsstormfilter(Broadcast,Multicast,Unicast)

 TheQoSsupports802.1pQoSandportratelimiting

 TheVLANincludesMTU,Port‐based&802.1QTagBased

 Supports4groupsofport‐basedVLAN

 Providesporttrunk,onegroupwithtwomemberports 

 Providesportmirroring

 SupportsIGMPsnoopingv1/v2/v3

 Supportsloopdetectionandprevention

 Providescabletestingfunction

 SupportsDHCPclient

 SupportsDHCPsnooping

 FirmwareupdateviaHTTPandTFTP

 Supportsconfigurationbackup&restore

 Supportsresettofactorydefaultbutton
