8‐PortGigabitWeb‐SmartSwitch

24|Page



MTUmulti‐tenantunitVLAN

Thisisaone‐clicksolutionwhichgeneratesaVLANsetupwhereoneportis

accessiblefromallotherports,buttheothersevenportsareisolatedfromone

another.Apossibleapplicationcouldbeanapartmentbuildingwhereupto7

familiesshareanInternetconnection.TheInternetRouterorGatewayis

connectedtoport1whereastheother7familiesareconnectedtoports2–8.



5.1 VLANModeSetting

SelecttheVLANmodeyouwishtouse.



5.2 PortBasedVLAN

Allowsyoutoassignportstovirtualnetworks.DatafromaportthatisamemberofaVLANgroupis

restrictedtoothermembersofthatVLANgroup.Thisfeatureprovidesaneasywaytopartitionanetwork

intoprivatesubnetworks.




