TL6000, Users
Rev L, June 2008
Page 11 of 22
The default value for the baud rate is 9600 baud (bits/sec). This setting
only affects the printer output.
Changing the baud rate:
Press the MODE key nine times until the display reads ‘b rt
b rtb rt
b rt ’. Press and
hold the MODE key until the display reads ‘Edit
EditEdit
Edit’. Change the value using
the arrow keys. To save your data, press and hold the MODE key until
the display reads ‘Save
SaveSave
Save’. The system will return to measurement mode.
ANALOG OUT
This optional feature allows a 0V to 2V analog voltage that is spanned
linearly by the applied weight to the tension link. The capacity the user
sets equals the maximum voltage level (2.0V) and no weight applied
equals 0V. All other voltage levels will be linear (ratio metric) with the
weight value. For example, if the applied weight is ½ the capacity, the
voltage will be 1.0V. The analog output is utilized by the connector on the
side of the scale.
Enabling or Disabling analog output
Press the mode key ten times until the display reads “A Out
A OutA Out
A Out”. Press and
hold the MODE key until the display reads ‘Edit
EditEdit
Edit’. Press the up and down
keys to change the setting. ‘1’ enables the analog out and ‘0’ disables the
analog out. To save your data, press and hold the MODE key until the
display reads ‘Sav
SavSav
Save
ee
e’. The system will return to measurement mode.
Enable 1
Disable 0
SCALE ID
The scale ID parameter is used when you have a wireless TL6000
system. Each TL6000 scale must have a different scale ID (1 to 20).
Changing the scale ID:
Press the MODE key until the display reads ‘SC Id
SC IdSC Id
SC Id ’. Press and hold the
MODE key until the display reads ‘Edit
EditEdit
Edit’. Change the value using the
arrow keys. To save your data, press and hold the MODE key until the
display reads ‘Save
SaveSave
Save’. The system will return to measurement mode.
ZERO
Tells the scale to display a zero weight. This key is used any time the scale
shows a non-zero value with no weight on the scale. If you press ZERO with
weight on the hook, that weight becomes the zero condition for the scale. This
can be useful to cancel the weight of chains or cables. When this weight is
removed, a negative weight shows until the system is zeroed again.
The zero point is saved into memory. This means you can turn the scale off and
