How to calibrate the scale
The following details the calibration procedure for the tension scale. All parameters can
be set without the calibration strap. If the cal strap is in place, only the first four
parameters may be calibrated.
Step Function Note
Default
rd rt
rd rtrd rt
rd rt
Read Rate 1 to 7 (see table) 4
Azt
AztAzt
Azt
Auto Zero Tracking 0=off, 1=1, 2=2, 3=3 3
GrAd
GrAdGrAd
GrAd
Graduations 0 to 12 (see table) 6
CAP
CAPCAP
CAP
Capacity Enter Capacity
Information saved
Check Cal Strap
LOAd0
LOAd0LOAd0
LOAd0
Zero Read No weight applied
LOAd1
LOAd1LOAd1
LOAd1
First weight Enter first weight
LOAd2
LOAd2LOAd2
LOAd2
Second weight Enter second weight
LOAd3
LOAd3LOAd3
LOAd3
Third weight Enter third weight
LOAd4
LOAd4LOAd4
LOAd4
Fourth weight Enter fourth weight
LOAd5
LOAd5LOAd5
LOAd5
Fifth weight Enter fifth weight
Start up
Note: Read section titled: How to enter a number
1) Turn scale power ON.
2) Wait for scale to warm up (3 minutes from power on).
3) Press ZERO and PEAK together and release to enter the calibration mode.
First four parameters
4) The scale shows ‘rd rt
rd rtrd rt
rd rt ’. The read rate is the number of internal reads per
second the scale performs. A higher setting will result in a faster responding
scale, but will also use the battery life more quickly. Press ZERO and PEAK
together to edit the read rate. Enter the read rate (1 to 7).
Note: When you plan to connect the TL6000 to a cabled or wireless TL6000
remote, set the read rate to (3) or less for best results.
Read Rate Readings / sec
1 1
2 2
3 4
4 7
5 10
6 18
7 25
