TL6000, Users
Rev L, June 2008
Page 3 of 22
Introduction
This manual contains specifications, operation instructions, and calibration instructions
for Intercomp's model TL6000 tension link.
Specifications
Controls
General: On/Off, Mode, Zero, Peak, Tare
Display: 1.2” 5 digit LCD.
Indicators: 9 display icons
Electrical
Batteries: 1 or 2 standard or Ni-Cad 9V cells
Battery life: Standard: Approximately 800 hours battery life on 2 Alkaline
cells, 400 hours on 1 Alkaline cell.
Wireless version: 50 hours / 25 hours.
Resolution: 14 bit A/D delivers over 16,000 internal counts
Filtering: Analog and digital
Sleep mode: Operates in low-power mode after adjustable time without use
or motion.
Auto off: Low battery, or after adjustable time without use or motion.
Auto Zero: Selectable 1, 2, or 3 graduations
Outputs: RS232, RS485, 0V-2V analog, 2 Set Points (3.3V logic level)
Optional cabled or wireless connection to a TL6000 Remote.
Performance
Accuracy: For capacities 500 lb – 10,000lb: ±0.1% of applied load or ± 1
division, whichever is greater.
For capacities 25,000 lb and higher: ±0.2% of applied load or
± 2 divisions, whichever is greater.
Environmental
Humidity: 10 to 95% Non-Condensing.
Temperature: Operating: -10 C to +40 C / +14 F to +104 F.
Storage: -40 C to +75 C / -40 F to +170 F.
