Main Menu - Additional Installer Information
4
-
Output Control
The two onboard relays are defaulted as Door 1 and Door 2 control and are
controlled when an intercom session is established between an outdoor station
and NX-181xx Voice keypads.
Relay trigger events are selectable and can be chosen from a drop down
“Activation events” list from within the web interface. Events can only be selected
from within the NX-595E web interface.
Note: From the activation event drop down list “” output 1 trigger” “ and ” output 2
trigger” are fixed X10 module commands 0 and 1. When selected, they can be
controlled directly from within Menu 4-output control when connected to a NX-
595E.
Drop down Event X10 Module Number
Output 1 trigger 0
Output 2 trigger 1
Additional relay boards (NX-507) can be added, with a system total of 16. An
output from a NX-181xx or NX-595E is an X10 command that can be tied to
different relays. Set the relay you wish to control to follow event 56 (follow X10
command). Then tie the relay to the output by setting the corresponding X10
module number (from the chart below) at the X10 address for the relay. Please
refer to your NX-507 installation instructions for further details.
Note: NX-508 output boards can also be used.
Outputs
X10 Module
Number
Outputs
X10 Module
Number
1 0 9 8
2 1 10 9
3 2 11 10
4 3 12 11
5 4 13 12
6 5 14 13
7 6 15 14
8 7 16 15
0
-
System Configuration
0.1 User Configuration

Interlogix NX-595E Specifications

General

Quantity	1
Compatibility	V2 (NX-4, NX-6, NX-8, NX-8E, NX-7, NX-9, NX-10, NX-11)
Operating temperature (T-T)	0 - 49 °C

Weight and Dimensions

Depth	90 mm
Width	220 mm
Height	45 mm
Weight	130 g
Dimensions (WxDxH)	220 x 90 x 45 mm
