26 NX-595E Installation Manual
The screen shot above shows the NX-595E’s complete menu when accessed via
an installer code.
Network settings, location list, outputs and IP reporting will not be presented
when accessed via a master code and only Arm/Disarm and Sensors will display
if a standard user code is used to access the NX-595E. Make your programming
selection by clicking on one of the left tabs.
Note: The NX-595E must either be in program mode, or alternately Location 19,
Option 6 must be enabled before the NX-595E will present network settings,
location list, outputs or IP reporting, even when accessed via an installer code.
Users
The user configuration menu is where user PIN codes are assigned to users.
The authorisation level determines the options available to that user, user
authorisation is where you would alter and increase a users authority to become
a Master Code. Master codes can only create, delete or modify user codes with
equal or less authority than themselves.
The user configuration menu is where you also assign partition control and adjust
authorisation levels to each user. Assigning partitions to users, determines which
sections (partitions) of the security system a user may access.
Important: You must create a user name for your customer to enable them to
login to the NX-595E. The installer account is for installer access only. Write the
user name and PIN code on the back page of the User Manual.

Other manuals for Interlogix NX-595E

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Interlogix NX-595E and is the answer not in the manual?

Interlogix NX-595E Specifications

General IconGeneral
Quantity1
CompatibilityV2 (NX-4, NX-6, NX-8, NX-8E, NX-7, NX-9, NX-10, NX-11)
Operating temperature (T-T)0 - 49 °C
Weight and Dimensions IconWeight and Dimensions
Depth90 mm
Width220 mm
Height45 mm
Weight130 g
Dimensions (WxDxH)220 x 90 x 45 mm
