Protocol settings
Use SW1 switches 5, 6 and 7 to set the PTZ dome protocol.
Refer to Table 2 below:
Table 2: Set the dome protocol
Protocol
SW1 switch no.
5 6 7
UTC RS-485 OFF OFF OFF
PROTOCOL_PELCO_P ON OFF OFF
PROTOCOL_PELCO_D OFF ON OFF
PROTOCOL_DIGIPLEX ON ON OFF
PROTOCOL_RS422_ASCII OFF OFF ON
PROTOCOL_BOSCH_CODE OFF ON ON
PROTOCOL_AD_CODE ON ON ON
HD-TVI mode settings
Use SW1 switch number 8 to set the HD-TVI mode of the PTZ
dome. HD-TVI Mode 1.0 and HD-TVI Mode 2.0 are two
standards to transfer HD-TVI signals. HD-TVI Mode 1.0
supports a short transmission distance with a wide bandwidth
while HD-TVI Mode 2.0 supports a long transmission distance
with a narrow bandwidth. Refer to the Table 3 below:
