27Filter Pump Installations
Receiver
Power
Supply
120V
240V
Neutral Bus
Hot Line #1
Hot Line #2
High Speed #1
Low Speed #2
Common
2-Pole Breaker
Figure 4-7. Wiring Circuits #1 & #2 to a 240 VAC 2-Speed Pump for PE653RC.
