19 Installing — Ratings, 120V/240V Wiring, Power In/Out
240V Wiring Applications
This Installation Guide covers most typical applications. If you need more instructions for 240V or
specic applications (i.e. water feature, auxiliary devices), please go to http://www.intermatic.com
to access the MultiWave Congurator for more wiring diagrams or call technical support for
assistance.
Power to/from PE653RC
NOTE: Contact Tech Support at Intermatic for additional diagrams.
Hot Line #1
2-Pole Breaker
Hot Line #2
Hot Line #1
RECEIVER
POWER
SUPPLY
NEUTRAL BUS
120V
240V
Figure 3-4. Wiring 240V incoming power to PE653RC.
