www.intermatic.com
44
MultiWave Control System Installation Guide
Chapter 7:
Blower/Chlorinator/Sensors
PE653RC with Blower
Neutral Bus
2-Pole Breaker
Hot Line #1
Hot Line #2
Hot Line
#2
240 VAC
Blower
Receiver
Power
Supply
120V
240V
Figure 7-1. Wiring Circuit #2 to a 240 VAC Blower for PE653RC.
