9
Chapter 1:
Overview
IMPORTANT: The installer must fill out the MultiWave Pool & Spa Control System
Worksheet for Programming at the back of this guide so that the controller can be
programmed.
The MultiWave Control System brings wireless control to a new level of simplicity. It features
push button control and a clear, easy-to-read backlit display panel. This manual provides
guidelines and instructions for installing the MultiWave Control System.
(PE653) Receiver
(2T2485GA)
Enclosure
Figure 1-1. PE653RC MultiWave Control System.
Water Temperature
Sensor (PA122)
PE953 Controller
Overview
