Chapter 1— Getting Started
12 3400, 3440, and 3600 Bar Code Label Printer User’s Manual
To configure the printer serial port
1 Use the following DIP switch setting descriptions and table to locate the
DIP switches you need to change to configure the serial port.
2 Use a small straight-slot screwdriver to set the appropriate DIP switches.
For example, if you want to change the media type to thermal transfer,
set DIP switch 8 on the bottom bank of switches to the on position.
3 Turn the printer power off and then on for the configuration changes to
take effect.
Note: Ignore Multi-Drop switches if you are not using a Multi-Drop
network.
DIP Switch Setting Descriptions
Parameter Description
Baud rate The rate, in bits per second, at which the host exchanges
data with the printer.
Parity Adds one bit (1 or 0) to the character to make the sum of
bits always odd or even.
Data bits The number of bits that represent the ASCII characters.
Stop bits Timing units between characters that synchronize character
transmission.
Multi-Drop address Unique address for each device connected with Multi-Drop
protocol.
Protocol The transmission standards for communication between the
printer and each connecting device.
Media type Enables the printer to work with either direct thermal or
thermal transfer media.
The following table provides the maximum baud rates for the printers.
Maximum Printer Baud Rates
Printer Maximum Baud Rate
3400A 19,200
3400B 19,200
3400C 38,400
3400D 38,400
3440 57,600
3600 19,200
