Appendix A— Specifications
70 3400, 3440, and 3600 Bar Code Label Printer User’s Manual
Printer Specifications
Electrical Requirements
Input Voltage 100, 120, or 240 VAC ± 10%
Frequency 47-63 Hz
Environment
Operating 10°C to 40°C (50°F to 104°F)
Humidity 10% to 90% non-condensing
Communications
• Asynchronous RS-232C, RS-422, RS-485 interfaces
• Serial ASCII code
• Hardware (Ready/Busy) Flow Control
• XON/XOFF Protocol
• Intermec Standard Block Protocol
• Polling Mode D Protocol
• Multi-Drop Protocol
• Baud Rates: 1,200, 2,400, 4,800, 9,600, 19,200, 38,400, 57,000
Maximum Printer Baud Rates
Printer Maximum Baud Rate
3400A 19,200
3400B 19,200
3400C 38,400
3400D 38,400
3440 57,600
3600 19,200
Printing Method
The 3400, 3440, and 3600 printers are capable of direct thermal (DT)
printing or thermal transfer (TTR) printing using thermal transfer ribbon.
