Intermec EasyCoder F4 – Installation & Operation Ed. 3106
Appendix 3 Interfaces
USB Interface
The EasyCoder F4 has, as standard, two serial communication
interfaces: RS-232 on "uart1:" (see previous page) and USB. To use
the USB interface for printing from a PC, you need a special USB
printer driver installed in your PC.
Using an USB Class A - B cable, connect the Class A end to your PC
or hub and the Class B end to your EasyCoder F4 printer.
USB = Universal Serial Bus
USB Class A connector.
Connect to PC or hub.
USB Class B connector.
Connect to USB receptacle on the printer’s rear plate.
Note:
The USB interface is presently not supported by the Intermec
Fingerprint programming language (v7.40).
USB
