Intermec EasyCoder F4 – Installation & Operation Ed. 3 59
Chapter 7 Setting Up the Printer
LTS (Label Taken Sensor)
The sensitivity of the LTS may need to be adjusted according to
ambient light conditions and refl ective characteristics of the back
side of the media. The LTS setup options are only displayed if an
optional label taken sensor is installed in the printer.
• LTS Adjust
Press <Enter>. A label is fed out. Remove the label and press
<Enter> again. A menu shows the sensitivity automatically
selected by the fi rmware and the range, in which the LTS
will work. Press <Enter> again and you will proceed to the
LTS Test menu.
• LTS Test
Press <Enter>. A label is fed out. Remove the label and a new label
should be fed out automatically. Repeat until you are sure the LTS
works properly. Then press <Enter> to stop and exit.
• LTS Value
Press <Enter>. You can enter a new value in the range indicated
in the LTS Adjust menu (see above). Min/max values are in
the range 0 to 10.
If an optional EasyLAN 100i interface board is fi tted, a number
of additional setup menus will appear. These menus are used
for setting up the IP address, the netmask, and the default router
for the EasyLAN 100i board, as described in separate manuals
delivered with the board.
Print Defi nes, cont.
Network
• IP Selection
• IP Address
• Netmask
• Default router
