Intermec EasyCoder F4 – Installation & Operation Ed. 3 49
Chapter 7 Setting Up the Printer
New Line
This parameter is only shown if an optional EasyLAN 100i interface
board is installed. It is used to select the characters transmitted
from the printer to specify the switching to a new line. There
are three options:
• CR/LF ASCII 13 dec. + ASCII 10 dec. (default)
• LF ASCII 10 dec.
• CR ASCII 13 dec.
The Feedadjust part of the Setup Mode controls how much of
the media is fed out or pulled back before and/or after the actual
printing. These settings are global and will be effected regardless
of which program is run.
Note that the fi rmware detects the front edges of labels with gaps,
the ends of detection slots, and the forward edges of black marks,
all seen in relation to the feed direction.
Start Adjust
The Start Adjust value is given as a positive or negative number
of dots (1 dot = 0.125 mm = 4.9 mils). Default value is 0, which
places the origin a certain distance back from the forward edge
of the copy.
• A positive start adjustment means that the specifi ed length of
media will be fed out before the printing starts. Thus, the origin is
moved further back from the forward edge of the copy.
• A negative start adjustment means that the specifi ed length of
media will be pulled back before the printing starts. Thus, the
origin is moved towards the forward edge of the copy.
Stop Adjust
The Stop Adjust value is given as a positive or negative number of
dots (1 dot = 0.125 mm = 4.9 mils). Default value is 0, which stops the
media feed in a position suitable for tear off operation.
• A positive stop adjustment means that the normal amount of
media feed after the printing is completed will be increased
by the specifi ed value.
• A negative stop adjustment means that the normal amount of
media feed after the printing is completed will be decreased
by the specifi ed value.
Setup Parameters, cont.
Feedadjust
• Startadjust
• Stopadjust
Net Communication
• New Line
Recommended Feed
Adjustments
The following settings allow
printing from the top of the
label. Minor deviations from
the recommended values may
be required due to various com-
binations of media types, roll
size, type of media supply device,
and individual differences bet-
ween printers.
Tear-Off:
Start adjust: -100 (-12.5 mm)
Stop adjust: 0 (0 mm)
Peel-Off:
Start adjust: -56 (-7.0 mm)
Stop adjust: -44 (-5.5 mm)
