Intermec EasyCoder F4 – Installation & Operation Ed. 310
Chapter 2 Printing a Label
Baud rate: 9600
Character length: 8
Parity: none
Stop bits: 1
Flowcontrol: none
New line: CR/LF
If you want to change any of these values, refer to Chapter 8, “Setup
Mode.” Set up the host computer for the same communication
protocol as the printer.
Media Supply
Load the printer with labels at least 35 mm (1.4 inches) wide
and at least 40 mm (1.6 inches) long, see Chapter 5. In case of
thermal transfer printing, also load a suitable thermal transfer
ribbon, see Chapter 6.
If the printout becomes too light or too dark, you will need to
change the paper type parameter. For help, see Chapter 8, “Setup
Mode.”
Startup and Communications Check
Switch on the printer. Provided the printer is not fi tted with any
custom-made startup program, after initialization the Intermec Shell
countdown menu will appear in the display window:
ENTER=SHELL
5 sec. v.4.4
4 sec. v.4.4
3 sec. v.4.4
2 sec. v.4.4
1 sec. v.4.4
Do not take any action. By default, the display window will show the
following message when the countdown is completed:
Fingerprint
7.40
If this message is not shown, refer to “Selecting an Application” in
Chapter 9 to select the “Fingerprint” application.
