Intermec EasyCoder F4 – Installation & Operation Ed. 396
Appendix 1 Technical Data
Sensors
Label Gap/Black Mark/Out of Media Yes 5 fi xed positions
Printhead Lifted Yes
Ribbon End/Ribbon Low
Controls
Control Lamps 3
Display 2 x 16 character LCD w. background light
Keyboard 22 keys membrane-switch type
Print button 1
Beeper Yes
Data Interfaces
Serial 1 x RS-232 + 1 x USB
Bar Code Wand 1 For setup
Electronic Keys 2 Future option
Connection for Optional Interface Boards 1
Memory Card Adapter 1 Flash or SRAM cards
Accessories and Options
Integral Self-strip Unit with Liner Takeup Option For peel-off operation
Rotating Media Supply Hub Option Replaces supply post
3-inch Adapter for Media Supply Hub Option
Short Side Door Option
3
Long Side Door Option
3
Long Side Door with 8-inch Megatop Option
3
Label Taken Sensor Option
Real Time Clock Option 10+ years life
RS-232 Cable Option
EasySet Bar Code Wand Option For quick setup
Parallel Interface Board Option IEEE 1284
Double Serial Interface Board Option
Industrial Interface Board Option
EasyLAN 100i Interface Board Option Ethernet
External Alphanumeric Keyboard Option
Flash Memory Cards Option ≤ 64 Mbit (8 MB)
Electronic Keys Option
1
/. The max. print length is also restricted by the amount of free DRAM memory.
2
/. Latin, Greek, and Cyrillic fonts according to Unicode standard are included.
3
/. Type of door fi tted at delivery depends on model.
Technical Data, cont.
