Intermec PX4i

Appendix A — Specifications
146 PX4i and PX6i High Performance Printer User’s Manual
Self-Adhesive Strip
Liner (b)
The liner must not extend more than a total of 1.6 mm (0.06 in)
outside the face material and should protrude equally on both sides.
Media Type
Set media type to one of these values:
• Fingerprint:
• FIX LENGTH STRIP
• VAR LENGTH STRIP
• IPL: CONTINUOUS
External Media Width Including Liner (a)
Printer Measurement Value
PX4i Maximum 120 mm (4.72 in)
Minimum 25.0 mm (1.00 in)
PX6i Maximum 170 mm (6.69 in)
Minimum 76.0 mm (3.00 in)
External Media Width Excluding Liner (c)
Printer Measurement Value
PX4i Maximum 118.4 mm (4.66 in)
Minimum 23.8 mm (0.94 in)
PX6i Maximum 168.4 mm (6.63 in)
Minimum 74.4 mm (2.93 in)
