8
Version 1.0 (11/2007) en
Original language
Product information
RollerDrive EC200
Product identification
To identify a RollerDrive, the following information is required. You may enter the
values of your RollerDrive in the last column.
Technical data
Information Possible value Own value
RollerDrive label Motor type
Gear ratio
RollerDrive EC200
Tube diameter 50 mm or 1.9 in
Tube material Zinc-plated, galvanized,
aluminum or stainless steel (with
or without sleeves)
Roller length RL
US
or RL
EU
(see "RL
definition", page 13)
Roller transmission see "Groove locations", page 15
Idler shaft Spring-loaded or floating
(see "Dimensions of idler
cartridges", page 14)
Nominal voltage 24 VDC
Voltage range 18 to 28 VDC
No load current 0.4 A
Maximum continuous current 2.1 A
Maximum peak current 5.5 A
Mechanical performance 25 W
System efficiency (drive) 49 %
Maximum ripple from power supply 3 %
Noise emission (mounted) 55 dB(A)
Lifetime under nominal conditions 15000 h
Maximum start/stop per minute 30
Protection classification IP54 (IP66)
Ambient temperature for operation 0 °C to 40 °C (32 °F to 104 °F)
Ambient temperature for transport and
storage
-20°C to 75°C (-4°F to 167°F)
Ambient temperature changes max. 1 °K/min; 3 h; two cycles
according to IEC 68-2-14
Ambient humidity max. 90% not condensing
Installation altitude above sea level max. 1000 m (max. 3300 ft)
Hint
• UL approval is not required for RollerDrive products as they operate under a
recommended maximum voltage of 30 VDC. The RollerDrive EC200 is
recognized as an UL Class II product.
• Mechanical performance, performance data and performance charts are on
basis of 20 °C (68 °F).
