28
Version 1.0 (11/2007) en
Original language
Appendix
RollerDrive EC200
Appendix
Accessories
Belts
DriveControls
Wiring accessories
Part Characteristics
Toothed belt • Gates Poly-Chain GT or similar: pitch 8 mm (0.31 in)
• Toothed belt width: 11.2 mm (0.44 in)
• Hub with 18 teeth
Round belt • Belts of 4 mm (0.16 in) and max. 5 mm (0.20 in)
diameter
Multi-rib belt • Drive head with 9 grooves for flexible V-ribbed belts
• PJ form, ISO 9981, DIN 7867
• Pitch 2.34 mm (0.09 in)
• Belts with a max. of 4 ribs
Part Part #
DC-EC200/EC300 (13:1) 89QU
Z-Card EC Easy 89Z2
Z-Card EC Full 89Z3
Part Characteristics Part #
Power supply 230 V / 150 W / 24 VDC 89NT
Extension cable
RollerDrive - DriveControl
Length 1600 mm 89VK
Extension cable
RollerDrive - Z-Card EC
Length 1000 mm
Length 2000 mm
89VE
89VF
