Assembly
RollerDrive EC200
Assembly
Warning notices concerning assembly
¾ Do not drop or mishandle the RollerDrive to avoid internal damage.
¾ Check each RollerDrive visually for damage before assembly.
¾ Do not hold, carry, or support the RollerDrive by the wires extending out of
the mounting shaft to avoid damage to the internal solder joints.
¾ Do not force the RollerDrive when inserting it into the conveyor frame. It
should fit easily into the holes in the frame.
¾ Ensure that the proper torque (see assembly instructions) is applied to the
RollerDrive hex nut to prevent the shaft spinning in the frame and the wires
twisting.
¾ Do not twist the motor cable.
Rotating parts and accidental motor starts
Risk of pinched fingers
¾ Do not insert fingers between the RollerDrive and the
O-ring belt, multi-rib belt or roller chain.
¾ Install a protection device (such as a guard plate) to
prevent fingers from getting trapped in the O-ring belt,
multi-rib belt or roller chain.
¾ Install an appropriate warning on the conveyor.
Risk of damage leading to failure or shortened life
expectancy of the RollerDrive
¾ Observe the following notices.
