Troubleshooting
RollerDrive EC200
Troubleshooting
Error search
Risk of injury due to accidental motor starts
¾ Error search may only be executed by qualified and
authorized persons.
¾ Only perform error search after switching off the power.
Ensure that the RollerDrive cannot be turned on
accidentally.
¾ Use caution while searching the error.
CAUTION
Symptom Possible cause Help
RollerDrive is not operating. No power supply Check 24 VDC power supply.
Plugs not connected properly Check cable connection.
RollerDrive is rotating in the wrong
direction or at the wrong speed.
Wrong DriveControl setting at speed
and direction rotary switch
Change setting on DriveControl.
Wrong voltage at speed setting pin
(if the RollerDrive is not operated
with the recommended Interroll
DriveControl)
Check the voltage of the speed setting
pins at the motor plug.
Abnormal noise coming out of the
RollerDrive.
Motor or gearbox is damaged. Replace RollerDrive.
Interrupted RollerDrive operation Damaged motor cable Check motor cable for damages.
If motor cables are damaged, replace
RollerDrive.
RollerDrive overload see "Overload protection devices",
page 7
