3. Before Starting the Installation
34
Gigabit ETH cable for service Traffic, Inband Management
and Powering
, Continued
Cabling
overview using
DC PoNE,
continued
The following schematic shows a cabling overview of OSDR radio unit when
powering is through an outdoor AC PoNE:
GbE#2 and GbE#OUT Gigabit Ethernet (S-FTP) cable for traffic,
inband management and superimposed DC
power.
GbE#IN, Gigabit Ethernet (S-FTP) cable for traffic and
inband management.
AC-IN AC power supply cable.
GND Grounding cable 16 mm
2
.
Continued on next page
