Outdoor Software Defined Radio (OSDR) platform
Installation & Cabling Manual - Edition 3.0
67
Panel Antenna, Continued
Mounting kit installation procedure, continued
Step Action
3 Perform the following actions:
B: Place the radio mounting adapter onto the OSDR, as shown below.
C: Install and screw the four screws.
Do not over tighten. Adjust the tool for max tightening torque 4.2 Nm.
Continued on next page
