Invacare CS3 User Manual

5 TECHNICAL DATA
Invacare ®CS Series Beds
24 Part No 1153410
Electrical Specifications
CS3 CS5 CS7 CS9 CS9FX600
Control box mains voltage
120V~ 120V~
120V~ or
230V~
120V~ or
230V~
120V~
Control box input current
3.5A max 3.5A max
3.5A max
(1.5A max
for 230V~
models)
3.5A max
(1.5A max
for 230V~
models)
3.5A max
Control box current frequency
60 Hz 60 Hz
60 Hz (50
Hz for 230 V
models
60 Hz (50
Hz for 230
V models
60 Hz
Control box output voltage 24 VDC (70W max)
Control box duty cycle 10% Max (2 min ON 18 min OFF)
Motorized linear head actuator 24 Volts DC
Motorized linear actuators (head, foot,
and HI/LO)
24 Volts DC
Six button hand pendant standard not available
Eight button hand pendant with contour
function
not available standard (10 button optional)
Attendant control panel (ACP) optional
Trendelenburg ACP not available optional
