5 TECHNICAL DATA
Invacare ®CS Series Beds
28 Part No 1153410
5.2 Mattress Specifications
A mattress may not be included with this bed. It is highly recommended that you use an Invacare branded mattress that is designed to
conform to the following dimensions:
WARNING
Possible patient ENTRAPMENT Hazard if using non-specified mattress.
Refer to the Bed Rail Entrapment Risk Notification Guide at www.invacare.com.
Use only a mattress of recommended specifications with this bed.
Named Size Minimum Size Maximum Size
Length 76 in (1930.4 mm) 75 in (1905 mm) 76 in (1930.4 mm)
80 in (2032 mm) 79 in (2006.6 mm) 80 in (2032 mm)
84 in (2133.6 mm) 83 in (2108.6 mm) 84 in (2133.6 mm)
Width 36 in (914 mm) 35.5 in (911 mm) 36.5 in (927 mm)
39 in (991 mm) 38.5 in (978 mm) 39.5 in (1004 mm)
42 in (1067 mm) 41.5 in (1054 mm) 42.5 in (1080 mm)
Thickness 6 in (152 mm) 5.88 in (149 mm) 6.12 in (155 mm)
