6 SET-UP
Invacare ®CS Series Beds
32 Part No 1153410
6.2 Assembly Instructions
Install the Mattress Keeper Rod to the Head and Foot Decks
1. Press HI/LO UP button on the hand pendant. 2. After the bed is raised, cut the untrimmed or
green tie while holding the wall bumper.
3. Rotate the wall bumper to the floor at the head
end of the bed.
CAUTION
The Mattress Keeper Rods are an integral part of the bed rail system. by securing the mattress in place, the Mattress
Keeper Rods prevent unsafe gaps from forming between the bed ends or rails and the mattress. Install the Mattress
Keeping Rods correctly to prevent patient entrapment.
The mattress keeper rods hold the mattress in place. Install them in the head and foot decks.
