Invacare CS3 User Manual

5 TECHNICAL DATA
Part No 1153410
23 Invacare ®CS Series Beds
5 Technical Data
5.1 Typical Product Parameters
Certifications
All models (120 V~ models - CS3, CS5, CS7, CS9, CS9FX600 and 230 V~ models - CS7, CS9) conform to UL60601-1 and IEC60601-1.
Certified to IEC60601-2-38 and IEC60601-1-2 and CAN/CSA C22.2 No. 601.1
Elevation Range (floor to deck)
2
CS3 CS5 CS7 CS9 CS9FX600
Stability Range
(casters locked or off casters)
8¼ to 26½ in
(211 to 686
mm)
9 to 30 in
(229 to
762 mm)
7 to 30 in
(178 to 762
mm)
9 to 30 in
(229 to 762 mm)
Mobility range (on casters) 8¼ in (211 mm)
only
Angle between back section (head deck)
and deck platform
0° to 70°
Angle between back section and upper
leg section
>90°
Trendelenburg or reverse trendelenburg
(when configured)
not available 0° to 14° (Optional)
Under-bed clearance for
2
/
3
of bed -
centered
14 in (356 mm)
