8 OPTIONS
Part No 1153410
51 Invacare ®CS Series Beds
4 Function Pendant
Using the integrated Nurse Call Feature
1. Locate call cord cable at the head of the bed along with the power cord.
2. Route cable to nurse call wall outlet and insert call cable plug into socket.
3. Coil any extra cable and secure to the bed.
4. Test Nurse Call by pressing the red first aid button on the hand pendant.
Using the Underbed Light
1. The underbed light has pre-installed at the foot end of the bed. All cabling has been routed and secured to keep it from getting pinched during
normal operation of the bed.
WARNING
Extra cable should be routed and secured to bed to prevent tripping hazards. Otherwise injury may occur.
CAUTION
Route cable and secure to bed avoiding all pinch points. Otherwise damage to the cable and bed will occur.
In the event of a power failure or an issue occurs within the electronic system of your Invacare bed, the nurse call button
will be activated, and will not be reset until the electronic system is running properly. Remove the nurse call plug to disable
nurse call signal until service is preformed.
