8 OPTIONS
Part No 1153410
59 Invacare ®CS Series Beds
FIGURE6 Adjustable deck wings, knobs and snap buttons
Underside of Bed
Foot End
Head End
Adjustment
Knobs
Adjustment Knob Adjustment Knob Adjustment Knob
Adjustable Head Section Adjustable Seat
Section
Adjustable Thigh
Section
Adjustable Foot Section
Adjustment
Knobs
Adjustment Knob Adjustment Knob Adjustment Knob
Adjustable Head Section Adjustable Seat
Section
Adjustable Thigh
Section
Adjustable Foot Section
