10 TROUBLESHOOTING
Invacare ®CS Series Beds
66 Part No 1153410
Actuator not working. HI/LO lock-out is on. For non-openbus (CS3) - A Lockout
box (a square black box) with a
toggle switch. When the switch is
towards "ON" side, the HILO on
the hand pendant will not function.
There is no LED light.
For openbus beds (CS7, CS9) - The
lockout box (a flatter rectangular
white box) with a toggle dome
button and LED light. When the
light is on, the HILO on the hand
pendant will not function.
Rotate the lockout dial to the “unlocked” position
(horizontal), or flip switch to OFF.
Lockout LED on the Attendant
Control Pad (ACP) is ON.
Toggle-off the individual function lockout (LED should
be OFF)
Loose wire connections. Check cable connections visually. Connect any loose cable couplings and/or power
supplies.
Faulty actuator. Disconnect power supply, swap
cable from unresponsive actuator
with a functional actuator.
Reconnect power and test
functions. Faulty actuator will not
work regardless of the connection
port.
Contact Invacare Continuing Care Service
Department 1-800-668-2337.
EFFECT POSSIBLE CAUSE VERIFICATION CORRECTIVE ACTION
