Invacare®EtudePlus
3Setup
3.1GeneralSafetyInformation
WARNING!
Riskofinjuryordamage
Damagedpartsmayaffectthesafetyofthe
product.
–Checkallpartsforshippingdamagebeforeuse.
–Incaseofdamage,donotusetheproduct
andcontactyourInvacareproviderforfurther
instructions.
WARNING!
Riskofinjuryordamagetoproperty
Theassemblyofthebedandinstallationof
accessoriesmustonlybeperformedbyaqualied
technicianorapersonwhohasreceivedproper
training.
–Followinstructionscarefully.Ifyouhaveany
questionregardingtheassembly,contactyour
Invacareprovider.
–Theelectricalequipmentofthebedmustnot
bedismantledorcombinedwithotherelectrical
equipment.
–Aftereachassembly,checkthatallttingsare
properlytightenedandthatallpartshavethe
correctfunction.
NOTICE!
–Topreventcondensation,thebedshould
notbeuseduntilithasreachedoperating
temperature.See9TechnicalData,page23
3.2Receivingthebed
A
B
C
D
E
G
F
H
I
J
Scopeofdelivery:
A
Mattresssupport,headend
B
Mattressretainers,4pcs
C
Siderails(woodorsteel),2pcs
D
Mattresssupport,footend
E
Motorforbedend
F
Castors,4pcs
G
Motorforheadend
I
Motorforlegend
J
Bedends,2pcs
Handcontrol(notshown)
Optional
H
Mattresssupportextension(10or20cm)
Liftingpole
Transporttting
Siderailsmightnotbepartoftheconguration.For
moreinformationaboutsiderailsandotheroptions,
contactyourInvacarerepresentative.
3.3OtherItems
Thefollowingitemsarealsoprovidedwithinthescopeof
delivery:
Part
Quantity
Usermanual
1
Entrapmentlabel
4
3.4Assemblyofthebed
WARNING!
–Aftereachassembly,checkthatallttingsare
tightenedcorrectlyandthatthefunctionofall
partsisgiven.
Mattresssupport
1.Placethetwoinsertsintheupperhalfofthemattress
support.Theinsertsmustbemountedinsuchaway
thatoneextendsfurtheroutofthesidetubethanthe
other.
2.Looselyscrewinthetwothumbscrews.
3.Pushthelowerhalfofthemattresssupportontothe
twoinserts.
4.Tightenwithtwothumbscrews.
5.Retightenthetwothumbscrewsattheheadendof
thetopframe.
6.Turnupthefourmattresssupportbrackets.
7.Turnthehandleofthelegsectionup.
